Dynacord TGX10
Gotovina/virman
Dynacord TGX10 – DSP pojačalo snage 4 x 2500W, 4-kanalno DSP pojačalo za live primjene Gustoća snage do 10kW u 2RU Potpuno integrirani DSP s naprednom obradom od 96 kHz i FIR Drive tehnologijom OMNEO integracija za besprijekornu kompatibilnost s Dante i OCA Zaslon u boji osjetljiv na dodir za upravljanje bez softvera IZLAZNA SNAGA: Maksimalna izlazna snaga, svi kanali pogonjeni: @2 Ω: 2600 W @2,7 Ω: 3000 W @4 Ω: 2500 W @8 Ω: 1250 W
CIJENA NA UPIT
4-channel DSP amplifier for live applications
Power density of up to 10kW in 2RU
Fully integrated DSP with advanced 96 kHz processing and FIR Drive technology
OMNEO integration for seamless compatibility with Dante and OCA
Full color touch screen for control without software
OUTPUT POWER:
Maximum Output Power, all channels driven:
@2 Ω: 2600 W
@2.7 Ω: 3000 W
@4 Ω: 2500 W
@8 Ω: 1250 W
AMPLIFIER:
Voltage gain ref. 1 kHz: 32.0 dB, adjustable 24-40 dB
Input Sensitivity ref. to Max. Output Voltage: 10.7 dBu (2.66 V), adjustable 2.7-18.7 dBu
THD 3 dB below Max., AES17, 1 kHz: less than 0.05 %
IMD-SMPTE, 60 Hz, 7 kHz: less than 0.05 %
DIM100, 3.15 kHz, 15 kHz: less than 0.15 %
Crosstalk ref. 1 kHz, 12 dB below Max., 8 Ω: less than -80 dB
Frequency Response ref. 1 kHz, analog in to speaker out: 20 Hz to 20 kHz
Damping Factor, 20 Hz to 200 Hz, 8 Ω: > 400
Output Stage Topology: Class D, fixed frequency
Protections: Audio Limiters, High Temperature, DC, HF, Short Circuit, Back-EMF, Peak Current Limiters, Inrush Current Limiters, Turn-on Delay, Mains Circuit Breaker Protection, Mains Over/ Under voltage Protection
Cooling: Front-to-rear, temperature controlled fans, supervised
Ambient Temperature Limits: +5 °C to +40 °C
IEC Protection Class: Class I (grounded)
Color: Black
Dimensions (W x H x D): 483 x 88.1 x 514.2 mm
Weight: 15.0 kg
