Eurolite MD-2010
Gotovina/virman
60,00 €
MD-2010 Sigurnosni rotacijski motor Motor za zrcalne kugle promjera do 50 cm Pogodan za pogon zrcalnih kugli do maksimalne težine od 10 kg Ova težina odgovara promjeru od 50 cm za zrcalne kugle EUROLITE
The maximum load always means the mirror ball weight including the mirror ball chain, the safety chain and the fixation material
2 chains and 4 quick links must be ordered separately
1 rotation per minute
Delivered with open cable-ends
For professional use, e.g. in discotheques and in public places, the EN DIN 15560 norms have to be considered
The motor always has to be installed with a secondary safety attachment
Before taking into operation for the first time, the installation has to be approved by an expert
Power supply: 230 V AC, 50 Hz
Maximum load WLL (4-fold): 30 kg
Maximum load BGV C1 (8-fold): 15 kg
Maximum load BGV C1 (10-fold): 12 kg
Maximum load BGV C1 (12-fold): 10 kg
Max. diameter of mirror ball: 50 cm (EUROLITE)
Rotation-speed: approx. 1 RPM
Diameter of base plate: 190 mm
Height: 130 mm
Weight: 1 kg
Power consumption: 3.50 W
