Gotovina/virman

370,00 €

MPC: ~~463,00 €~~

Instalacijsko miksersko pojačalo 35W @ 4 Ohma / 100 V / 70 V

Linijski ulaz za hitni signal sa zatvaranjem kontakta
2 ulazne utičnice za mikrofon/liniju s prekidačem za mikrofon/liniju i preklopnim fantomskim napajanjem od 24 V
Preklopna funkcija zvona u kanalu Mic/Line 1
2 linijska ulaza s RCA utičnicama i Bluetooth 4.0 sučeljem (mono sumirano)
35W pojačalo klase D s Lo-Z / Hi-Z prekidačem i izlazima 4 Ohma / 100V / 70V
Uravnoteženi AUX linijski izlaz s Music-Mix prekidačem, za upravljanje vanjskim pojačalima, aktivnim subwooferima ili sustavima za glazbu na čekanju
4 razine prioriteta za sveobuhvatne mogućnosti integracije
Preklopni automatski način rada u stanju pripravnosti za smanjenje potrošnje energije
Intuitivni dizajn upravljačke ploče za rad s kapacitivnim kontrolama za odabir izvora glazbe i Bluetooth uparivanje
Univerzalno širokopojasno preklopno napajanje

Mogućnost povrata robe
Slanje standardnih pošiljaka
Paletna dostava

Opis

Specifications:

General:
Product type: Installation mixer preamplifier
Emergency input: 1 balanced line input
Mic/ line inputs: 2
Music sources: 2 unbalanced stereo line inputs, Bluetooth 4.0
Line outputs: 1
Powered outputs: 1 with output mode selector (Low-Z/High-Z)
Cooling: Convection
Priority levels: 4

Emergency Input:
Nominal input sensitivity: -6 dBu (Sine 1 kHz, Gain max)
Nominal input clipping: 20 dBu (Sine 1kHz)
Connector: 5-pin Terminal Block, pitch 5.08mm

Mic/Line inputs 1-2:
Nominal input sensitivity Mic: – 36 dBu (Sine 1 kHz, Gain max)
Nominal input clipping Mic: – 17 dBu (Sine 1kHz)
Nominal input clipping line: Line +19dBu (Sine 1kHz)
Phantom power: + 24V, 10mA switchable
Connector Mic/Line 1: 5-pin Terminal Block, pitch 5.08mm, XLR/6.3 mm jack
Connector Mic/Line 2: 1 dual RCA Mono Summed, 3-pin Terminal Block, pitch 5.08 mm

Music inputs – CD/AUX:
Nominal input sensitivity CD/AUX: – 6.22 dBV (Sine 1 kHz, Gain max)
Nominal input clipping CD/AUX: 7.78 dBV (Sine 1kHz)
Connector CD/AUX: 2 x dual RCA Mono Summed

Amplifier Output:
Amplifier Outputs: Low-Z: 4 ohm minimum load, High-Z: 70V or 100V outputs
Preamplifier input: 5-pin Terminal Block, pitch 5.08mm
RMS Power: 35 W (Continuous sine wave 1kHz, 4 ohm load)
Power (Peak): 39 W (100 msec sine 1kHz burst @ 4 ohm load)
Frequency range: 60 Hz – 20 kHz (HI-Z, -3 dB), 20 Hz – 20 kHz (LO-Z, -3 dB)
Tone control Bass: +/-10dB (100Hz)
Tone control Treble: +/-10dB (100Hz)
Protection circuits: over-current, Short circuit, Audio Limiter, thermal overload

Aux Output:
Connector AUX-output: 3-pin Terminal Block, pitch 5.08 mm
Maximum gain: 22 dB

General data:
Operating voltage: 100 V AC – 240 V AC, 50 – 60 Hz
Power consumption (max.): 70 W
Idle power consumption: 7 W (no signal input)
Operating temperature (non-condensing): Non condensing, 0°C – 40°C; < 85% humidity
Time to Auto-standby: 20
Dimensions (W x H x D) (height with rubber feet): 210 x 96.5 x 266.76 mm
Optional accessories: Rack mounting hardware (LDTICARK)
