LD Systems XS 700
Gotovina/virman
385,00 €
PA pojačalo snage klase D, 2 x 350 W @ 4 Ohma XS700 je izuzetno kompaktno, pouzdano pojačalo snage klase D s izlaznom snagom od 350 W po kanalu pri 4 oma, odnosno 700 W u premoštenom načinu rada od 8 oma, te širokim rasponom prijenosa od 20 Hz do 20 kHz.
Specifications:
General:
Peak output power: 700 W
RMS output power: 400 W
Amp class: Class D
Frequency response (±0.5 dB, rel. Avg): 20 Hz – 20000 Hz
Protection features: Short circuit, Overheating, Overload
Inputs:
Number of line inputs: 3
Line-In connector type: XLR 3-pole female, RCA female, 6.3 mm Jack TRS female
Input gain: 24 dB – 30 dB
Outputs:
Number of speaker outputs: 2
Speaker output connection type: Standard speaker connector 4-pole male & speakON®, Speaker terminal 2-pole
Amplifier:
Output channels number: 2
Bridged output channels number: 1
Total RMS output power: 4 Ω: 700 W | 8 Ω: 400 W
Total Peak output power: 8 Ω: 700 W
Bridged output power (Peak): 8 Ω: 1 x 700 W
Mains operation:
Operation voltage: 115 V AC – 230 V AC / 50 – 60 Hz
Power supply type: Switched-mode power supply (SMPS)
Rated power: 860 W
Mains connector: IEC C14 plug male
Dimensions & weight:
Width: 482 mm
Height: 44 mm
Depth: 244 mm
Weight: 3.4 kg
